| Camera |
| Image Sensor: |
1/3" Progressive Scan CMOS
|
| Min. Illumination: |
0.07Lux @ (F1.2, AGC ON) ,0 Lux with IR
|
| Shutter time: |
1/25(1/30) s to 1/100,000 s
|
| Lens: |
4mm@ F2.0 (6mm, 12mm optional)
2048 × 1536:
Angle of view: 70°(4mm), 43.3°(6mm), 20.6°(12mm)
1920 × 1080:
Angle of view: 79°(4mm), 49°(6mm), 23.2°(12mm)
|
| Lens Mount: |
M12
|
| Day& Night: |
IR cut filter with auto switch
|
| Wide Dynamic Range: |
Digital WDR
|
| Digital noise reduction: |
3D DNR
|
|
| Compression Standard |
| Video Compression: |
H.264/M-JPEG
|
| Bit Rate: |
32 Kbps ~ 16 Mbps
|
| Dual Stream: |
Yes
|
|
| Image |
| Max. Image Resolution: |
2048×1536
|
| Frame Rate: |
50Hz: 20fps (2048 × 1536), 25fps (1920 × 1080), 25fps (1280 × 720)
60Hz: 20fps (2048 × 1536), 30fps (1920 × 1080), 30fps (1280 × 720)
|
| Image Settings: |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
|
| BLC: |
Yes, zone configurable
|
| ROI: |
Yes, up to 4 configurable areas
|
|
| Network |
| Network Storage: |
NAS
|
| Alarm Trigger: |
Motion detection, Dynamic analysis, Tampering alarm
|
| Protocols: |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
|
| Security: |
User authentication, watermark
|
| System Compatibility: |
ONVIF, PSIA, CGI, ISAPI
|
|
| Interface |
| Communication Interface: |
1 RJ45 10M / 100M ethernet interface
|
| Reset Button: |
Yes
|
|
| General |
| Operating Conditions: |
-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing)
|
| Power Supply: |
12 VDC ± 10%, PoE (802.3af)
|
| Power Consumption: |
Max. 5 W (Max. 7 W with IR cut filter on)
|
| Weather Proof: |
IP66
|
| IR Range: |
-I: Approx 20 to 30 meters(65.6-98.4ft)
|
| Dimensions: |
60.4×76.9×139.28 mm (2.4” × 3.0” × 5.5”)
|
| Weight: |
500g (1.1 lbs)
|
|
